P355N Steel Flanges and EN 1.0562/ P355NH Blind Flange manufacturer

EN 1.0562 Blind Flange and P355NH Carbon Steel Threaded Flange manufacturer in India

Table Of Content:

Material Specification P355nh
P355N Welding Neck Flange Price
Types Of P355N Steel Flange
P355n Equivalent ASTM Material
P355n Chemical Composition
P355n Mechanical Properties
P355n Temperature Range
P355n High Temperature Flange Yield Point
Why P355N called A285 grade C Steel?
Torque Values Of P355N Carbon Steel Flange
Benefits Of P355N Welding Neck Flange
P355N Pressure Vessel Steel Flanges Wall Thickness
Weight Of P355n Flange
Nace Mr0175 P355n Slip On Flange Dimensions

P355n TC1 EN 10216-3 Flange Facing Type
Tolerance Of Steel Grade P355n Flanges
P355n Steel Flanges Bolt And Nut Size
Surface Finish Of Werkstoff P355n Tc1 Flange
P355n Steel Pipe Flanges Sizes Chart
Pressure Vessel P355nh Flange Manufacturing Process
P355nh Carbon Steel Flanges Applications
Gaskets For EN1092-1 P355N Socket Weld Flange
EN 1.0562 Weld Neck Flange Dimensions
EN 1.0562 Blind Flange Dimensions

Material Specification P355nh

Specification	P355N Steel Flange
Manufacturer of	Forged/ Threaded/ Screwed / Plate
Schedule	SCH 5S, SCH 10, SCH 40, SCH 80, SCH 120, SCH 160, SCH 180 To XXS
Dimensions And Standard	ASME B16.5
Test Certificates	EN 10204/3.1B Raw Materials Certificate 100% Radiography Test Report Third Party Inspection Report, etc
Production Technique	Forged/ Heat treated and machined
Manufacturer Length	NPS 1⁄₂" To NPS 48”
Face Type	RTJ/ FF/ RF/ lap joint/ Male & Female / Tongue & Groove.
Forging Methods	Casting/ Forging/ Rolling/ Cutting
Supporting Material	Gasket/ Ring Joint/ Flange Bolts
Flange Test	Hydrostatic testing machine/ UI trasonic flaw detector/ X-ray detector/ Direct-reading Spectrograph/ Magnetic particle detector
Flange Equipment	Pushing Machine/ electric bevelling machine/ Press machine/ Bending machine/ Sand-blasting machine etc
Coating	Anti-rust Paint/ Zinc Plated/ Oil Black Paint/ Yellow Transparent/ Cold and Hot Dip Galvanized
Application	Bitumen upgraders Heavy oil refineries. Nuclear power (mostly seamless). Petrochemicals and acids.

Check Nace Mr0175 P355N Slip On Flange and Alloy Steel EN 1.0562 Weld Neck Flange Material Price list and dimensions

P355N Welding Neck Flange Price

Nominal Diameter	Nominal pipe size in mm	Pitch Circle Diameter In mm	Thread holes	Standard	Grade	Price In INR (India) Per Piece
DN 20	3/4" (26,9)	75	4 x 14 mm Ø	Pressure Vessel Steel	P355N	466.00
DN 25	1" (33,7)	85	4 x 14 mm Ø	-	-	684.00
DN 32	1.1/4" (42,4)	100	4 x 18 mm Ø	-	-	1126.00
DN 40	1.1/2" (48,3)	110	4 x 18 mm Ø	-	-	1390.00
DN 50	2" (60,3)	125	4 x 18 mm Ø	-	-	1750.00
DN 65	76,1	145	4 x 18 mm Ø	-	-	2650.00
DN 80	88,9	160	8 x 18 mm Ø	-	-	3150.00
DN 100	108	180	8 x 18 mm Ø	-	-	3787.00
DN 100	114,3	180	8 x 18 mm Ø	-	-	4500.00
DN 125	133	210	8 x 18 mm Ø	-	-	5190.00
DN 125	139,7	210	8 x 18 mm Ø	-	-	5400.00
DN 150	159	240	8 x 22 mm Ø	-	-	5985.00
DN 150	168,3	240	8 x 22 mm Ø	-	-	6400.00
DN 200	219,1	295	12 x 22 mm Ø	Pressure Vessel Steel	P355N	7228.00

Manufacturer of En1092-1 P355N Socket Weld Flange and EN 10216-3 P355NH Orifice Flanges in Flat Face/ Raised and Ring Type Joint

Types Of P355N Steel Flange

P355n Pressure Vessel Steel Flanges

P355n Flange

P355n Steel Pipe Flanges

Steel Grade P355n Flanges

P355nh Carbon Steel Flanges

En 10216-3 P355n Flange

En 1.0562 Blind Flange

En 1.0562 Weld Neck Flange

Nace Mr0175 P355n Slip On Flange

P355nh Carbon Steel Threaded Flange

En1092-1 P355n Socket Weld Flange

Werkstoff P355n Tc1 RTJ Flange

P355n Orifice Flange

En 10028-3 P355n Spectacle Blind Flange

P355n Tc1 En 10216-3 Plate Flange

P355n Din En 10216-3 Reducing Flange

P355n Tc1 Vanstone Flange

Din En10216-3 P355n Raised Face Flange

P355n Tc1 En 10216-3 Welding Flange

En1092-1 P355N Pipe Flange

P355N Low Temperature Flange

P355n Pressure Vessel Flange

P355n Flange

Steel Grade P355N Flange

Grade P355NH Forged Flange

EN 10028-3 P355NL2 Flange

EN 10028-3 P355N Flange

P355n Equivalent ASTM Material

DIN	DIN 17179 Grade FGP 36
EN	EN 10216-3 Grade P355N
BS	NFA A 49-326 Grade TU 52-BT
NFA	ASTM A381 Grade Y 52
ASTM	ASME SA381 Grade Y 52

P355n Chemical Composition

Sulphur	Molybdenum	Nickel	Chromium	Copper	Others	Carbon	Silicon	Manganese	Phosphorous
0.02	maximum 0.08	maximum 0.50	maximum 0.30	maximum 0.30	V maximum 0.10 Nb maximum 0.05 Ti maximum 0.04 Al min 0.020 Nb+Ti+V maximum 0.12	maximum 0.20	maximum 0.50	0.90-1.70	0.025

P355n Mechanical Properties

Yield Strength		Tensile Strength			Elongation A5 min
MPa minimum	ksi minimum	MPa minimum	MPa minimum	ksi minimum	Percentage
		490	650	–	22

EN 10216-3 P355N Alloy Steel Lap Joint Flange and EN 10028:3 P355NH Steel Spectacle Blind Flange supplier in India offers Final visual inspection reports with each order, check EN 10222-4 Grade P355NH Forged Flange pressure rating

P355N Temperature Range

Temperature	Value	Condition	Standards
20 °C	7.8 g/cm³	normalized or normalized formed (+N)	EN 10028-2
100 °C	205 GPa	normalized or normalized formed (+N)	EN 10028-2
200 °C	195 GPa	normalized or normalized formed (+N)	EN 10028-2
300 °C	185 GPa	normalized or normalized formed (+N)	EN 10028-2
400 °C	175 GPa	normalized or normalized formed (+N)	EN 10028-2
500 °C	175 GPa	normalized or normalized formed (+N)	EN 10028-2

P355N High Temperature Flange Yield Point

P235GH High Temperature Flange Yield Point

Why P355N Called A285 Grade C Steel?

Torque Values Of P355N Carbon Steel Flange

Flange Size Inch	Flange Size MM	(Maximum) Radial Projection
Flange Size Inch	Flange Size MM	No Deeper Than the Bottom In Millimeter	Deeper Than the Bottom In Millimeter
1/2	15	3.0	1.5
3/4	20	3.0	1.5
1	25	3.0	1.5
1 1/4	32	3.0	1.5
1 1/2	40	3.0	1.5
2	50	3.0	1.5
2 1/2	65	3.0	1.5
3	80	4.5	1.5
3 1/2	90	6.0	3.0
4	100	6.0	3.0
5	125	6.0	3.0
6	150	6.0	3.0
8	200	8.0	4.5
10	250	8.0	4.5
12	300	8.0	4.5
14	350	8.0	4.5
16	400	10.0	4.5
18	450	12.0	6.0

Benefits Of P355N Welding Neck Flange

P355N Pressure Vessel Steel Flanges Wall Thickness

Normal Size Of Pipe	Outer Diameter (O.D.)	10 Schedule	20 Schedule	30 Schedule	STD Wall	40 Schedule	60 Schedule	EXT Hvy	80 Schedule	100 Schedule	120 Schedule	140 Schedule	160 Schedule	XX Hvy
½	0.84	0.083	...	...	0.109	0.109	...	0.147	0.147	...	...	...	0.188	0.294
¾	1.05	0.083	...	...	0.113	0.113	...	0.154	0.154	...	...	...	0.219	0.308
1	1.315	0.109	...	...	0.133	0.133	...	0.179	0.179	...	...	...	0.25	0.358
1 ¼	1.66	0.109	...	...	0.14	0.14	...	0.191	0.191	...	...	...	0.25	0.382
1 ½	1.9	0.109	...	...	0.145	0.145	...	0.2	0.2	...	...	...	0.281	0.4
2	2.375	0.109	...	...	0.154	0.154	...	0.218	0.218	...	...	...	0.344	0.436
2 ½	2.875	0.12	...	...	0.203	0.203	...	0.276	0.276	...	...	...	0.375	0.552
3	3.5	0.12	-	-	0.216	0.216	-	0.3	0.3	-	-	-	0.438	0.6
3 ½	4	0.12	-	-	0.226	0.226	-	0.318	0.318	-	-	-	-	0.636
4	4.5	0.12	-	-	0.237	0.237	-	0.337	0.337	-	0.438	-	0.531	0.674
5	5.563	0.134	-	-	0.258	0.258	-	0.375	0.375	-	0.5	-	0.625	0.75
6	6.625	0.134	-	-	0.28	0.28	-	0.432	0.432	-	0.562	-	0.719	0.864
8	8.625	0.148	0.25	0.277	0.322	0.322	0.406	0.5	0.5	0.594	0.719	0.812	0.906	0.875
10	10.75	0.165	0.25	0.307	0.365	0.365	0.5	0.5	0.594	0.719	0.844	1	1.125	1
12	12.75	0.18	0.25	0.33	0.375	0.406	0.562	0.5	0.688	0.844	1	1.125	1.312	1
14	14	0.25	0.312	0.375	0.375	0.438	0.594	0.5	0.75	0.938	1.094	1.25	1.406	-
16	16	0.25	0.312	0.375	0.375	0.5	0.656	0.5	0.844	1.031	1.219	1.438	1.594	-
18	18	0.25	0.312	0.438	0.375	0.562	0.75	0.5	0.938	1.156	1.375	1.562	1.781	-
20	20	0.25	0.375	0.5	0.375	0.594	0.812	0.5	1.031	1.281	1.5	1.75	1.969	-
22	22	0.25	-	-	0.375	-	-	0.5	-	-	-	-	-	-
24	24	0.25	0.375	0.562	0.375	0.688	0.969	0.5	1.219	1.531	1.812	2.062	2.344	-
26	26	-	-	-	0.375	-	-	0.5	-	-	-	-	-	-
30	30	0.312	0.5	0.625	0.375	-	-	0.5	-	-	-	-	-	-

Weight Of P355n Flange

Pressure Class	Nominal Size Of Pipe (NPS)	Slip On (SORF Flange)	Threaded (NPT Flange)	Socket Weld (SWRF Flange)	Lap Joint (LOOSE Flange)	Blind (BLR FlangeF)	Weld Neck (WNRF Flange)
Class 150 Flange	½	1	1	2	1	2	2
	¾	2	2	2	2	2	2
	1	2	2	2	2	2	3
	1¼	3	3	3	3	3	3
	1½	3	3	3	3	4	4
	2	5	5	5	5	5	6
	2½	8	8	8	8	7	10
	3	9	9	9	9	9	11.5
	3½	11	12	11	11	13	12
	4	13	13	13	13	17	16.5
	5	15	15	15	15	20	21
	6	19	19	19	19	27	26
	8	30	30	30	30	47	42
	10	43	43	43	43	70	54
	12	64	64	64	64	123	88
	14	90	90	90	105	140	114
	16	106	98	98	140	180	140
	18	130	130	130	160	220	165
	20	165	165	165	195	285	197
	22	185	185	185	245	355	225
	24	220	220	220	275	430	268

Nace Mr0175 P355n Slip On Flange Dimensions

Dimensions of Class 150, 300, 600, 900, 1500, 2500

CLass	150	300	600	900	1500	2500
Diameter A	30	38	38	38	38	...
Diameter D	90	95	95	120	120	...
THK B	9.6	12.7	14.3	22.3	22.3	...
THK B	11.2	14.3	20.7	28.7	28.7	...
Diameter G	35.1	35.1	35.1	35.1	35.1	...
Diameter K	60.3	66.7	66.7	82.6	82.6	...
Height	14	21	22	32	32	...
Height	15.6	22.6	28.4	38.4	38.4	...
Number L	4	4	4	4	4	...
Diameter L	15.9	15.9	15.9	22.2	22.2	...
Stud Bolts Diameter x Length
Diameter (in)	1/2	1/2	1/2	3/4	3/4	...
Length mm	55	65	75	110	110	...

Purchasing P355N Steel Plate Flange and EN 10216-3 Grade P355NH Drip Ring Flange from the manufacturer directly saves your cost and time

P355n TC1 EN 10216-3 Flange Facing Type

Type A: Flat Face (FF)
Type B: Raised Face (RF)
Type C: Tongue Face (TF)
Type D: Grooved Face (GF)
1Type E: Spigo
Type F: Recess
Type G: Ring Recess
Type H: O-Ring Groove

Tolerance Of Steel Grade P355n Flanges

P355N Steel Flange	Diameter	Tolerance
(A)	(Outer Diameter)	When Outer Diameter is 24 Inch or less: ±1/16" (1.6 mm) When Outer Diameter is over 24": ±1/8" (3.2 mm)
(D)	(Inner Diameter)	10 Inches and smaller: ±1/32" (0.8 in mm) 12 Inches thru 18": +1/8" (3.2 in mm) 20 Inches and larger: -1/16" (1.6 in mm)
(B)	Contact Face	1/16" (RF): ±1/32" (0.8 mm) 1/4" (RF), Tongue And Groove (male And female): ±1/64" (0.4 mm)
(J)	Hub At Base Dai.	When hub base is 24 inches or smaller: ±1/16" (1.6 millimeter) When hub base is over 24": ±1/8" (3.2 millimeter)
(H)	Diameter of hub at point of welding	5 inch or smaller: +3/32" (2.4 mm), -1/32" (0.8 millimeter) 6 inch or larger: +5/32" (4.0 millimeter), -1/32 (0.8 mm)
(P)	Drilling	(B.C.): ±1/16" (1.6 mm) (B.H.) spacing: ±1/32" (0.8 mm)
	Eccentricity of (bc) with respect to facing	2 1/2" or smaller ±1/32" (0.8 mm) max. 3" or larger ±1/16" (1.6 mm) max.
(C)	(W.T.)	18 inch or smaller: ±1/8" (3.2 mm), -0" 20 inch or larger: ±3/16" (4.8 mm), -0"
(K)	hub Length	10 Inch or smaller: ±1/16" (1.6 millimeter) 12 Inch or larger: ±1/8" (3.2 millimeter)

P355n Steel Flanges Bolt And Nut Size

	Class 150				Class 300				Class 600
NPS	# Studs And Bolts	Diameter of Studs And Bolts	Length of Stud		# Studs And Bolts	Diameter of Studs And Bolts	Length of Stud		# Studs And Bolts	Diameter of Studs And Bolts	Length of Stud
			1/16 RF	RTJ			1/16 RF	RTJ			1/4 RF	RTJ
1/2	4	0.50	2-1/4	–	4	0.50	2-1/2	3	4	0.50	3	3
3/4	4	0.50	2-1/2	–	4	0.63	3	3-1/2	4	0.63	3-1/2	3-1/2
1	4	0.50	2-1/2	3	4	0.63	3	3-1/2	4	0.63	3-1/2	3-1/2
1-1/4	4	0.50	2-3/4	3-1/4	4	0.63	3-1/4	3-3/4	4	0.63	3-3/4	3-3/4
1-1/2	4	0.50	2-3/4	3-1/4	4	0.75	3-1/2	4	4	0.75	4-1/4	4-1/4
2	4	0.63	3-1/4	3-3/4	8	0.63	3-1/2	4	8	0.63	4-1/4	4-1/4
2-1/2	4	0.63	3-1/2	4	8	0.75	4	4-1/2	8	0.75	4-3/4	4-3/4
3	4	0.63	3-1/2	4	8	0.75	4-1/4	4-3/4	8	0.75	5	5
3-1/2	8	0.63	3-1/2	4	8	0.75	4-1/4	5	8	0.88	5-1/2	5-1/2
4	8	0.63	3-1/2	4	8	0.75	4-1/2	5	8	0.88	5-3/4	5-3/4
5	8	0.75	3-3/4	4-1/4	8	0.75	4-3/4	5-1/4	8	1.00	6-1/2	6-1/2
6	8	0.75	4	4-1/2	12	0.75	4-3/4	5-1/2	12	1.00	6-3/4	6-3/4
8	8	0.75	4-1/4	4-3/4	12	0.88	5-1/2	6	12	1.13	7-1/2	7-3/4
10	12	0.88	4-1/2	5	16	1.00	6-1/4	6-3/4	16	1.25	8-1/2	8-1/2
12	12	0.88	4-3/4	5-1/4	16	1.13	6-3/4	7-1/4	20	1.25	8-3/4	8-3/4
14	12	1.00	5-1/4	5-3/4	20	1.13	7	7-1/2	20	1.38	9-1/4	9-1/4
16	16	1.00	5-1/4	5-3/4	20	1.25	7-1/2	8	20	1.50	10	10
18	16	1.13	5-3/4	6-1/4	24	1.25	7-3/4	8-1/4	20	1.63	10-3/4	10-3/4
20	20	1.13	6-1/4	6-3/4	24	1.25	8	8-3/4	24	1.63	11-1/4	11-1/2
24	20	1.25	6-3/4	7-1/4	24	1.50	9	10	24	1.88	13	13-1/4

	Class 900				Class 1500				Class 2500
NPS	# Studs And Bolts	Diameter of Studs And Bolts	Length of Stud		# Studs And Bolts	Diameter of Studs And Bolts	Length of Stud		# Studs And Bolts	Diameter of Studs And Bolts	Length of Stud
			1/4 RF	RTJ			1/4 RF	RTJ			1/4 RF	RTJ
1/2	4	0.75	4-1/4	4-1/4	4	0.75	4-1/4	4-1/4	4	0.75	4-3/4	4-3/4
3/4	4	0.75	4-1/2	4-1/2	4	0.75	4-1/2	4-1/2	4	0.75	5	5
1	4	0.88	5	5	4	0.88	5	5	4	0.88	5-1/2	5-1/2
1-1/4	4	0.88	5	5	4	0.88	5	5	4	1.00	6	6
1-1/2	4	1.00	5-1/2	5-1/2	4	1.00	5-1/2	5-1/2	4	1.13	6-3/4	6-3/4
2	8	0.88	5-3/4	5-3/4	8	0.88	5-3/4	5-3/4	8	1.00	7	7
2-1/2	8	1.00	6-1/4	6-1/4	8	1.00	6-1/4	6-1/4	8	1.13	7-3/4	8
3	8	0.88	5-3/4	5-3/4	8	1.13	7	7	8	1.25	8-3/4	9
4	8	1.13	6-3/4	6-3/4	8	1.25	7-3/4	7-3/4	8	1.50	10	10-1/4
5	8	1.25	7-1/2	7-1/2	8	1.50	9-3/4	9-3/4	8	1.75	11-3/4	12-1/4
6	12	1.13	7-1/2	7-3/4	12	1.38	10-1/4	10-1/2	8	2.00	13-1/2	14
8	12	1.38	8-3/4	8-3/4	12	1.63	11-1/2	11-3/4	12	2.00	15	15-1/2
10	16	1.38	9-1/4	9-1/4	12	1.88	13-1/4	13-1/2	12	2.50	19-1/4	20
12	20	1.38	10	10	16	2.00	14-3/4	15-1/4	12	2.75	21-1/4	22
14	20	1.50	10-3/4	11	16	2.25	16	16-3/4	–	–	–	–
16	20	1.63	11-1/4	11-1/2	16	2.50	17-1/2	18-1/2	–	–	–	–
18	20	1.88	12-3/4	13-1/4	16	2.75	19-1/2	20-3/4	–	–	–	–
20	20	2.00	13-3/4	14-1/4	16	3.00	21-1/4	22-1/4	–	–	–	–
24	20	2.50	17-1/4	18	16	3.50	24-1/4	25-1/2	–	–	–	–

Surface Finish Of Werkstoff P355n Tc1 Flange

Normal Pipe Size	(A)	(B)
1/2	3.0	1.5
3/4	3.0	1.5
1	3.0	1.5
1-1/4	3.0	1.5
1-1/2	3.0	1.5
2	3.0	1.5
2-1/2	3.0	1.5
3	4.5	1.5
3-1/2	6.0	3.0
4	6.0	3.0
5	6.0	3.0
6	6.0	3.0
8	8.0	4.5
10	8.0	4.5
12	8.0	4.5
14	8.0	4.5
16	10.0	4.5
18	12.0	6.0
20	12.0	6.0
22	12.0	6.0
24	12.0	6.0

P355n Steel Pipe Flanges Sizes Chart

Pressure Vessel P355nh Flange Manufacturing Process

P355nh Carbon Steel Flanges Applications

Specialty Chemicals
Power Generation
Condensers
Chemical Equipment
Gas Processing
Pulp and Paper Industry

Sea Water Equipment
Pharmaceutical Equipment
Off-Shore Oil Drilling Companies
Petrochemicals
Heat Exchangers
Pharmaceuticals

Gaskets For EN1092-1 P355N Socket Weld Flange

(Normal Size Of Steel Pipes) In Inch	(I.D.) Inner Daimeter Gasket	(O.D.) Outer Daimeter Gasket
(Normal Size Of Steel Pipes) In Inch	(I.D.) Inner Daimeter Gasket	Class 150#/ LB	Class 300#/ LB	Class 400#/ LB	Class 600#/ LB	Class 900#/ LB
1/2	0.84	1.875	2.125	2.125	2.125	2.50
3/4	1.06	2.25	2.625	2.625	2.625	2.75
1	1.31	2.625	2.875	2.875	2.875	3.125
1 1/4	1.66	3	3.25	3.25	3.25	3.50
1 1/2	1.91	3.375	3.75	3.75	3.75	3.875
2	2.38	4.125	4.375	4.375	4.375	5.625
2 1/2	2.88	4.875	5.125	5.125	5.125	6.50
3	3.50	5.375	5.875	5.875	5.875	6.625
4	4.50	6.875	7.125	7.00	7.625	8.125
5	5.56	7.75	8.50	8.375	9.50	9.75
6	6.62	8.75	9.875	9.75	10.50	11.375
8	8.62	11	12.125	12.00	12.625	14.125
10	10.75	13.375	14.25	14.125	15.75	17.125
12	12.75	16.125	16.625	16.50	18.00	19.625

EN 1.0562 Weld Neck Flange Dimensions

Dimensions of Class 150, 300, 600, 900, 1500, 2500

CLass	CLass 150	CLass 300	CLass 600	CLass 900	CLass 1500	CLass 2500
Diameter A	30	38	38	38	38	43
Diameter D	90	95	95	120	120	135
Thickness B	9.6	12.7	14.3	22.3	22.3	30.2
Thickness B	11.2	14.3	20.7	28.7	28.7	36.6
Diameter G	35.1	35.1	35.1	35.1	35.1	35.1
Diameter K	60.3	66.7	66.7	82.6	82.6	88.9
Hight	46	51	52	60	60	73
Hight	47.6	52.6	58.4	66.4	66.4	79.4
Number L	4	4	4	4	4	4
Diameter L	15.9	15.9	15.9	22.2	22.2	22.2
Stud Bolts Diameter x Length
Diameter (in)	1/2	1/2	1/2	3/4	3/4	3/4
Length mm	55	65	75	110	110	120

EN 1.0562 Blind Flange Dimensions

Dimensions of Class 150, 300, 600, 900, 1500, 2500

CLass	CLass 150	CLass 300	CLass 600	CLass 900	CLass 1500	CLass 2500
Diameter D	90	95	95	120	120	135
B	9.6	12.7	14.3	22.3	22.3	30.2
B	11.2	14.3	20.7	28.7	28.7	36.6
Diameter G	35.1	35.1	35.1	35.1	35.1	35.1
Diameter K	60.3	66.7	66.7	82.6	82.6	88.9
Number L	4	4	4	4	4	4
Diameter L	15.9	15.9	15.9	22.2	22.2	22.2
Stud Bolts Diameter x Length
Diameter (in)	1/2	1/2	1/2	3/4	3/4	3/4
Length mm	55	65	75	110	110	120
